ViewSonic LS951WU Laser Projector 8000 ANSI Short Throw WUXGA
Model: LS951WU
Warranty: 3 years
Quick Specs:
- Brightness: 8,000 ANSI Lumens (8,100 Center Lumens)
- Native Resolution: 1920×1200 (WUXGA)
- Contrast Ratio: 3,000,000:1
- Light Source: Laser Phosphor (2nd Generation, up to 30,000 hours in SuperEco Mode)
- Throw Ratio: 0.75-0.95
- Net Weight: 13kg
Introducing the ViewSonic LS951WU from ViewSonic’s Luminous Superior Series, tailored for expansive venue displays. Featuring a robust 8,000 ANSI Lumens brightness and a high native contrast provided by a 0.67″ DMD chip through DLP technology, it delivers stunning visuals on screens up to 300 inches.
With a 0.75-0.95 short throw, the LS951WU delivers a seamless image on a 100-inch screen from only 1.6 meters away without shadows, enabling effortless edge blending to create immersive experiences. Motorized focus, zoom, lens shift, and H/V keystone adjustment make setup a breeze, while portrait mode and 360° projection capabilities cater to more advanced requirements.
Comprehensive LAN control ensures seamless integration into existing device management networks. Employing advanced 2nd generation laser phosphor technology, the ViewSonic LS951WU boasts a remarkable 30,000-hour lifespan, reducing maintenance costs for both business and educational institutions. For venues that need 4K UHD resolution instead of WUXGA, the similarly-positioned ViewSonic LS950-4K offers 7,100 ANSI Lumens in a standard-throw installation body.
Brilliant Visuals for Large Venues
With an impressive 8,000 ANSI Lumens, the LS951WU ensures crystal-clear visuals even in brightly lit environments. Its WUXGA resolution provides stunningly detailed images, enhancing the impact of presentations, training sessions, and events. This makes it the preferred choice for large venues such as auditoriums, assembly halls, receptions, and museums.
No Shadows, No Blinding Lights
Enjoy big-screen viewing without space constraints with the ViewSonic LS951WU, which features a 0.75-0.95 short throw ratio to project a stunning 100″ image from just 1.6 meters away. Perfect for auditoriums, exhibitions, and event spaces, this short throw technology reduces shadows and glare, ensuring clear, unobstructed projections for an immersive visual experience.
Unmatched Contrasts, Enhanced Visibility
Experience enhanced visuals with the LS951WU, boasting high contrast thanks to DLP technology and an advanced 0.67″ DMD chip from Texas Instruments. This provides deeper blacks and richer depth, ensuring an exceptional viewing experience.
Ultra-Large Screen with Lower Cost-per-Inch
This easy-to-install projector allows for an image size of up to 300″, offering a lower cost-per-inch compared to other types of commercial displays.
Enhanced Installation Flexibility (Motorized 1.26x Optical Zoom & Focus)
Equipped with a 1.26x optical zoom, the projector allows users to choose the ideal setup location within a range, achieving the desired image size without altering the existing interior design. Conveniently fine-tune the zoom and focus using the remote control, ensuring seamless operation without needing to access the ceiling-mounted projector.
Convenient Placement Setup (Motorized H/V Lens Shift)
The tool-free lens shift control knobs allow you to adjust the projection up, down, left, and right without moving the projector. Additionally, you can also adjust the image position directly via the remote control from a distance. It provides flexible installation options with a wide adjustable range (H: +/- 25%, V: +/- 55%) and minimal placement restrictions.
Get Perfectly-Shaped Images Effortlessly (H/V Keystone Correction, 4 Corner Adjustment)
Horizontal and vertical keystone correction along with 4-corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.
Centralized Control for Management Efficiency (Comprehensive LAN Control)
The ViewSonic LS951WU is compatible with Crestron, AMX, PJ Link, ATEN, and Extron systems, allowing for centralized device management for better operational efficiency.
Brilliant Colors for an Authentic Golf Experience (Golf Color Mode)
Powered by ViewSonic’s advanced color-tuning technology, the projector features a dedicated Golf Mode that enhances colors, especially greens and blues, more vivid and brings fairways and putting surfaces to life with striking realism, creating a golf experience that feels as close to reality as possible. The color mode is named as Sports Mode on the LS951WU.
2nd Generation Laser Phosphor Technology (Up to 30,000-hour Lifespan)
The ViewSonic LS951WU adopts the 2nd generation laser phosphor technology. In addition to inheriting excellent color performance, lamp-free design, and instant power on/off from the previous generation, technology on the new generation improves around 20% of brightness, better heat-resistance, and a smaller module design, making the images consistent in ambient settings as well as increased reliability with a more compact size for extended use in various scenarios.
Reliable Long-Term Performance with DLP Projection Technology
With DLP technology, the ViewSonic LS951WU maintains consistent color performance over time, free from any yellowing issues. Featuring a sealed engine design, it is filter-free, preventing dust from affecting internal components and ensuring minimal maintenance. Moreover, it offers crisp and seamless image quality, displaying remarkable contrast and eliminating the noticeable screen-door effect.
Versatile Creative Applications (360° Projection, 90° Portrait Mode)
The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.
Cost-Effective Long-Distance AV Signal Reception (Built-in HDBT Receiver)
With a built-in HDBT receiver, this projector can receive uncompressed high-resolution video and audio over long distances (up to 100m for 1080p) via a single Cat.5e/6 network cable and is compatible with any certified HDBaseT transmitter.
Seamless Edge-Blending
This projector features built-in software that automatically adjusts the brightness of overlapping image areas for smooth edge blending, simplifying the process and reducing costs. Compatible multi-output graphics card with an overlap function is required.
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily and onsite via a LAN webpage. This efficient solution, developed exclusively by ViewSonic, ensures optimal performance without the hassle.
ViewSonic LS951WU Specifications
Projection System: 0.67″ WUXGA
Native Resolution: 1920×1200
Brightness: 8000 (ANSI Lumens)
Brightness (Center Lumens): 8100
Contrast Ratio: 3000000:1
Display Color: 1.07 Billion Colors
Light Source Type: Laser Phosphor
Light Source Life (hours) with Normal Mode: 20000
Light Source Life (hours) with SuperEco Mode: 30000 (Eco)
Lens: F=2.3-2.53, f=11.11-14.06mm
Projection Offset: 0%±10%
Throw Ratio: 0.75-0.95
Optical Zoom: 1.26X
Digital Zoom: 0.5x-4.0x
Image Size: 50″- 300″
Throw Distance: 0.81-6.13m (100″@1.61m)
Keystone: H:+/-30°, V:+/-15°
Lens Shift V. Range: +55%, -55%
Lens Shift H. Range: +25%, -25%
Audible Noise (Normal): 32dB
Audible Noise (Eco): 30dB
Input Lag: 19ms
Resolution Support: VGA(640 x 480) to 4K(3840 x 2160)
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Horizontal Frequency: 15K-135KHz
Vertical Scan Rate: 23-120Hz
Computer in (share with component): 1
HDMI: 2 (HDMI 2.0, HDCP 1.4/2.2)
Audio-in (3.5mm): 1
3D VESA (Sync): 1 (BNC)
HDBaseT: 1
IR In: 1
HDMI out: 1
Audio-out (3.5mm): 1
Speaker: 10W x2
USB Type A (Power): 1 (5V/1.5A)
12V Trigger (3.5mm): 1
3D SYNC Out: 1
RS232 (DB 9-pin male): 1
RJ45 (LAN control): 1
Wired Remote Control – In: 1 (share with IR in)
Power Supply Voltage: 100-240V+/- 10%, 50/60Hz (AC in)
Power Consumption: Normal: 560W, Standby: <0.5W
Operating Temperature: 5~40°C
Net Weight: 13kg (28.66 lbs)
Gross Weight: 17.6kg (38.8 lbs)
Dimensions (WxDxH) with Adjustment Foot: 486x395x186mm (19.1×15.6×7.3 in)
Packing Dimensions: 654x563x373mm (25.7×22.2×14.7 in)
Standard Accessories: Power Cord (1), Remote Control (1, w/ backlit), Quick Start Guide
