Epson LQ-590IIN Network 24-Pin Dot Matrix Printer
Model: LQ-590IIN
Warranty: 12 Months Carry-in
Download Datasheet
Quick Specs:
- 24-pin Impact Printer
- Print speeds of up to 487 cps (10 cpi)
- 128 kb memory buffer
- MTBF of 25,000 POH
- Built-in network connectivity
Epson LQ-590IIN Overview
The Epson LQ-590IIN comes with built-in network connectivity and is designed to offer busy offices extraordinary speed, output quality and reliability. Based on Epson’s experience in delivering industry-standard solutions, this printer helps you run and grow your business and stay in control of your operations. Easily manage and print seven-part forms* and reports at print speeds of up to 487 characters per second (cps) to deliver fast results and speedy transactions. Moreover, with a high character yield of up to 5 million characters, you can do more with less.
* For continuous paper only.
Epson LQ-590IIN Key Features
Increased Productivity
Enjoy maximum productivity with fast print speeds of up to 487 cps (10 cpi) and 128 kb memory buffer.
Long-life Reliability
Enjoy cost savings, superior print quality and minimal downtime with a MTBF of 25,000 POH.
Absolute Convenience
Experience fuss-free printing with built-in network connectivity via Ethernet cable.
What’s In The Box
- Main Unit
- CD-ROM
- Set-up Manual
- AC Power Cable
- Ribbon Cartridge
- Guide Stacker
- Wing
- Tractor
Epson LQ-590IIN Specifications
Printing Technology
Print Method: Impact dot matrix
Control Panel: 6 switches and 10 LEDs
Print Direction: Bi-direction
Control Code: ESC/P2, IBM PPDS
Number of Pins: 24
Print Speed
Ultra High Speed Draft: 10 cpi: 550cps
High Speed Draft: 10/12 cpi: 487 / 584 cps
Draft: 10/12 cpi: 366 / 439 cps
NLQ: 10/12 cpi: 121 / 145 cps
Reliability
Printhead Life: 400 million strokes/wire
MVBF: 50 million lines (except print head)
MTBF: 25,000 Power On Hours (POH) (25% Duty)
Paper Path
Manual Insertion: Front or Rear in, Top out
Push Tractor: Front or Rear in, Top out
Pull Tractor: Front, Rear or Bottom in, Top out
Paper Media
Cut Sheet (Single Sheet): Front/Rear Entry, Length 100-364mm, Width 100-257mm, Thickness 0.065-0.14mm
Cut Sheet (Multi-part Forms): Front Entry, Length 100-364mm, Width 100-257mm, Thickness 0.12-0.46mm, Copies 1 Original + 5 copies
Continuous Paper (Single Sheet / Multi-part): Front/Rear/Bottom Entry, Length 101.6-558.8mm, Width 101.6-254mm, Thickness 0.065-0.49mm, Copies Original + 6 copies
Envelope (No.6): Rear Entry, Length 92mm, Width 165mm, Thickness 0.16-0.52mm
Envelope (No.10): Rear Entry, Length 105mm, Width 241mm, Thickness 0.16-0.52mm
Label (Base Sheet): Bottom Entry, Length 101.6-558.8mm, Width 100-148mm, Thickness 0.16-0.19mm
Card: Front/Rear Entry, Length 100-148mm, Width 100-148mm, Thickness 0.22mm
Roll Paper: Rear Entry, Diameter 127mm, Width 216mm, Thickness 0.07-0.09mm
Line Spacing: 4.23mm (1/6″) or programmable in increments of 0.0706mm (1/360″)
Options
Single Bin Cut Sheet Feeder – C12C806372
Pull Tractor Unit – C12C933761
Ribbon Cartridge – C13S015589
High Capacity Cut Sheet Feeder – C12C806382
Environmental Conditions (Operating)
Temperature: 5-35°C
Humidity: 10-80% RH
Acoustic Noise: 55 dB
Interface
USB 2.0, Bi-directional parallel (IEEE-1284 nibble mode supported), Serial, 100base-Tx wired LAN
Printable Columns
Pitch: 10cpi: 80 columns
Ribbon Cartridge
Standard: Fabric Ribbon Cartridge (Black)
Ribbon Life: Approx. 5 million characters
Supported Operating System
Printer Driver: Microsoft Windows XP / Vista / 7 / 8 / 10
Utility: Epson Status Monitor 3, Epson Setting Utility
