Epson LQ-2090IIN Network 24-Pin Dot Matrix Printer
Model: LQ-2090IIN
Warranty: 12 Months On-site
Download Datasheet
Quick Specs:
- 24-pin wide carriage
- Speed: Up to 487 cps (10cpi)
- Prints up to 7-part forms
- 25,000 power on hours MTBF
- USB 2.0, Bi-directional Parallel, Serial, Built-in network connectivity
Epson LQ-2090IIN Overview
Enjoy fast, reliable and convenient printing with Epson’s LQ-2090IIN dot matrix printer. Based on Epson’s experience in delivering industry-standard solutions, this printer helps to run and grow your business while you stay in control of your operations. Experience unparalleled durability and minimum downtime with a mean time between failure (MTBF) rating of 25,000 POH (power on hours) and printhead life of up to 400 million characters. A high character yield of up to 8 million means low running costs and more affordable prints.
Epson LQ-2090IIN Key Features
Increase Productivity
Enjoy maximum productivity with fast print speeds of up to 487 cps (10 cpi) and 128 kb memory buffer.
Multiple Copy Capability
High copy capability of up to 7 layers (1 original + 6 copies)* means sharp, clear documents right through the last copy.
Absolute Convenience
Experience fuss-free printing with built-in network connectivity via Ethernet cable.
* For continuous paper only.
What’s In The Box
- User’s manual
- Driver disc
- Ribbon cartridge (Black)
- Power supply cable
- Push tractor unit
- Rear sheet guide
Epson LQ-2090IIN Specifications
Printing Technology
Print Method: Impact dot matrix
Control Panel: 6 switches and 10 LEDs
Print Direction: Bi-direction with logic seeking
Number of Pins in Head: 24 pins
Control Code: ESC/P2, IBM PPDS
Print Speed
Ultra High Speed Draft: 10cpi: 550cps
High Speed Draft: 10/12 cpi: 487 / 584 cps
Draft: 10/12 cpi: 366 / 439 cps
Letter Quality: 10cpi: 121cps
Reliability
Printhead Life: 400 million strokes/wire
MVBF: 50 million lines (except printhead)
MTBF: 25,000 Power On Hours (POH) (25% Duty)
Paper Path
Manual Insertion: Front or Rear in, Top out
Push Tractor: Front or Rear in, Top out
Pull Tractor: Front, Rear or Bottom in, Top out
Paper Media
Cut Sheet (Single Sheet): Front/Rear Entry, Length 100-420mm, Width 100-420mm, Thickness 0.065-0.14mm
Cut Sheet (Multi-part Forms): Front Entry, Length 100-420mm, Width 100-420mm, Thickness 0.12-0.46mm, Copies 1 Original + 5 copies
Continuous Paper (Single Sheet / Multi-part): Front/Rear/Bottom Entry, Length 101.6-558.8mm, Width 101.6-406.4mm, Thickness 0.065-0.49mm, Copies 1 Original + 6 copies
Envelope (No.6): Rear Entry, Length 92mm, Width 165mm, Thickness 0.16-0.52mm
Envelope (No.10): Rear Entry, Length 105mm, Width 241mm, Thickness 0.16-0.52mm
Label (Base Sheet): Bottom Entry, Length 101.6-558.8mm, Width 101.6-406.4mm, Thickness 0.16-0.19mm
Card: Front/Rear Entry, Length 100-148mm, Width 100-148mm, Thickness 0.22mm
Roll Paper: Rear Entry, Width 216mm, Thickness 0.07-0.09mm
Line Spacing: 4.23mm (1/6″) or programmable in increments of 0.0706mm (1/360″)
Environmental Conditions (Operating)
Temperature: 5-35°C
Humidity: 10-80% RH
Acoustic Noise: 55 dB
Interface
USB 2.0, Bi-directional parallel (IEEE-1284 nibble mode supported), Serial, 100base-Tx wired LAN
Printable Columns
Pitch: 10cpi: 136 columns
Ribbon Cartridge
Standard: Fabric Ribbon Cartridge (Black)
Ribbon Life: Approx. 8 million characters
Supported Operating System
Printer Driver: Microsoft Windows XP / Vista / 7 / 8 / 10
Utility: Epson Status Monitor 3, Epson Setting Utility
