ViewSonic LS500WHE LED Business & Education Projector 3000 Lumens WXGA
Model: LS500WHE
Warranty: 3 years on-site (parts and labour)
“On-site” warranty means on-site pick and drop service only. It is not applicable to locations out of Singapore’s main island.
Please note: the ViewSonic LS500WHE is supplied without a carrying case as standard. An optional ViewSonic Carrying Case (PJ-CASE-008) is available as an add-on above for safer transport and storage.
Quick Specs:
- Brightness: 3,000 ANSI Lumens
- Resolution: WXGA (1280 x 800)
- Contrast Ratio: 3,000,000:1
- Light Source: LED, up to 30,000 hours
- Weight: 2.45 kg (net)
The ViewSonic LS500WHE is ViewSonic’s first lamp-free, 3,000 ANSI Lumens high brightness WXGA projector for business and education. Adopting industry-leading 3rd generation LED technology, it frees users from frequent lamp replacement and toxic mercury for a safer and greener environment, offering phenomenal lifespan of 30,000 hours, less power consumption, and true-to-life colors with 125% Rec.709.
The ViewSonic LS500WHE gives light to your presentations effortlessly with efficient instant power on/off and 360° tilt angle projection for flexible setup in small-to-medium sized meeting rooms and classrooms.
Key Features
Advanced 3rd Generation LED Technology
The latest 3rd generation LED technology eliminates toxic mercury and the cost and effort of frequent lamp replacement, offering consistently impressive brightness for up to 30,000 hours. Lamp Free, Mercury Free, Maintenance Free.
Enhanced Brightness for Business/Education Environments
With the latest LED technology, the ViewSonic LS500WHE achieves a major brightness breakthrough to 3,000 ANSI Lumens, ensuring bright and detailed images in dim or lit environments.
Higher Power Efficiency
Adopting ams OSRAM’s Ostar Projection Power LED technology, the LS500WHE saves nearly 50% more energy than competing lamp-based projectors.
Cinema SuperColor+™ Technology
Impress any audience with ViewSonic’s exclusive Cinema SuperColor+™ Technology, covering 125% Rec.709 wide color gamut for a rich, true-to-life color experience.
Efficient Instant Power On/Off
Eliminate waiting times before and after use with instant power on/off capability, delivering immediate full brightness for timely starts with no cooling period required.
360° Projection for Versatile Application
The projector can freely rotate at any angle vertically to aid with creative applications, allowing projection onto ceilings, walls, or angled signage.
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily and onsite via USB cable connection with your laptop.
USB Type A Power Supply
The built-in 5V/2A USB output conveniently delivers power to HDMI wireless dongles, eliminating the need for separate power adapters when streaming multimedia content. Browse Vonexhub’s full range of LED projectors for more mercury-free, maintenance-free options.
Sealed Optical Engine with IP5X
Maintain crystal-clear image quality and product longevity with an advanced sealed optical engine that prevents dust from entering and affecting the thermal system.
ViewSonic LS500WHE Specifications
| Display/Image | |
|---|---|
| Projection System | 0.65″ WXGA |
| Native Resolution | 1280 x 800 |
| Brightness | 3,000 ANSI Lumens |
| Contrast Ratio | 3,000,000:1 |
| Display Color | 1.07 Billion Colors |
| Resolution Support | VGA (640 x 480) to FullHD (1920 x 1080) |
| HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Horizontal Frequency | 15K – 102KHz |
| Vertical Scan Rate | 23 – 120Hz |
| Light Source | |
| Light Source Type | RGB LED |
| Light Source Life (Normal Mode) | up to 30,000 hours |
| Optical | |
| Lens | F=2.56-2.68, f=22-24.1mm |
| Projection Offset | 100% ±5% |
| Throw Ratio | 1.55 – 1.70 |
| Optical Zoom | 1.1x |
| Digital Zoom | 0.8x – 2.0x |
| Image Size | 30″ – 300″ |
| Throw Distance | 1.00 – 10.98m (100″ @ 3.34m) |
| Keystone | ± 40° (V) |
| Connectivity | |
| Input | HDMI: 1 (HDMI 1.4, HDCP 1.4), Audio-in (3.5mm): 1 |
| Output | Audio-out (3.5mm): 1, Speaker: 2W, USB Type A (Power): 1 (5V/2A) |
| Control | RS232 (DB 9-pin male): 1 |
| General | |
| Audible Noise (Normal) | 30dB |
| Audible Noise (Eco) | 26dB |
| Input Lag | 16ms |
| OSD Language | 24 languages, including English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T. Chinese, S. Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, India, Arabic, Vietnamese, Greek, Hungarian |
| Power | |
| Power Supply Voltage | 100 – 240V ±10%, 50/60Hz (AC in) |
| Power Consumption | Normal: 156W, Standby: <0.5W |
| Operating Temperature | 0 – 40°C |
| Weight and Dimensions | |
| Net Weight | 2.45kg |
| Dimensions (W x D x H, with Adjustment Foot) | 293 x 221 x 115mm |
| Standard Accessory | |
| Included | Power Cord, Remote Control, Quick Start Guide |
| Optional Accessory | |
| Wall/Ceiling Mount | PJ-WMK-007 |
| Carry Bag | PJ-CASE-008 |
