Epson DLQ-3500IIN Network 24-Pin Dot Matrix Printer
Model: DLQ-3500IIN
Warranty: 12 Months On-site
Download Datasheet
Quick Specs:
- Fast and durable wide carriage Epson 24 pin flat-bed printer
- Prints up to 550 characters per second
- Automatic paper handling and automatic paper thickness adjustment
- Prints up to 8 part forms (1 original + 7 copies)
- Built-in network connectivity via Ethernet cable
Epson DLQ-3500IIN Overview
Achieve detailed precision for your printing needs with Epson DLQ-3500IIN, the first dot matrix printer with colour LCD monitor panel. Built to deliver extreme print volume requirements and extraordinary output quality with print speeds of up to 550 characters per second (cps), up to eight-part forms with absolute accuracy as well as ribbon yield of up to 6 million characters, the versatile DLQ-3500IIN dot matrix printer is the ideal solution to maximise business efficiency.
What’s In The Box
- Ribbon cartridge (Black)
- Power Supply Cable
- CD Driver
- Front sheet guide
- User guide
Epson DLQ-3500IIN Specifications
Printing Technology
Print Method: Impact dot matrix
Control Panel: 13 switches and 3 LEDs with 1.44″ CLR LCD Screen
Print Direction: Bi-direction with logic seeking
Colour: Black
Number of Pins in Head: 24 pins x 2 (total 48 pins)
Control Code: ESC/P2 and IBM PPDS emulation
Print Speed
High Speed Draft: 10 cpi: 550 cps
Draft: 10 cpi: 550 cps, Condensed 17 cpi: 501 cps
Letter Quality: 10 cpi: 195 cps, Condensed 17 cpi: 333 cps
Reliability
Printhead Life: 200 million strokes/wire
MVBF: 25 million lines (except print head)
MTBF: 10,000 Power On Hours (POH)
Paper Path
Manual Insertion: Front in, front out
Push Tractor: Rear in, front out
Pull Tractor: Rear in, front out
Paper Media
Cut Sheet (Single Sheet): Length 80.0-420.0mm, Width 90.0-420.0mm, Thickness 0.065-0.19mm
Cut Sheet (Multi-part Forms): Length 80.0-420.0mm, Width 90.0-420.0mm, Thickness 0.12-0.62mm
Continuous Paper (Single Sheet / Multi-part): Length 76.2-558.8mm, Width 101.6-406.4mm, Thickness 0.065-0.19mm
Envelope (No.6): Length 92.0mm, Width 165.0mm, Thickness 0.16-0.52mm
Envelope (No.10): Length 105.0mm, Width 241.0mm, Thickness 0.16-0.52mm
Labels: Base Sheet Length (one page) 76.2-558.8mm
Card: Length 100.0-200.0mm, Width 100.0-200.0mm, Thickness 0.22mm
Copy: 1 original + 7 copies
Line Spacing: 4.23mm (1/6″) or programmable in increments of 0.0706mm (1/360″)
Dimensions and Weight
Dimensions (W x D x H): 661 x 433 x 276 mm
Weight: 18.9kg
Consumables
Ribbon Cartridge (Black): C13S015587
Environmental Conditions (Operating)
Temperature: 25-35°C
Humidity: 10-80% RH
Rated Voltage: AC 100-240V
Rated Frequency: 50-60 Hz
Power Consumption (Operating): Approx. 78W
Power Consumption (Sleep Mode): Approx. 1W
Acoustic Noise: Approx. 59 dB(A) (ISO 7779 pattern)
Input Data Buffer
128 KB
Interface
USB 2.0, Bi-directional parallel (IEEE-1284 nibble mode supported), 100base-Tx wired LAN
Printable Columns
Pitch: 10 cpi: 136 columns
Ribbon Cartridge
Standard: Fabric Ribbon Cartridge (Black)
Ribbon Life: Approx. 6 million characters
Supported Operating System
Printer Driver: Microsoft Windows XP / Vista / 7 / 8 / 10
Utility: Epson Status Monitor 3, Epson Setting Utility
