Eaton 5PX1500IRT2UG2 Line-interactive UPS – 1.50 kVA/1.50 kW – 2U Rack/Tower – 5 Minute Stand-by – 230 V AC Input – 200 V AC, 208 V AC, 220 V AC Output – 8 x IEC 60320 C13 (10A) Receptacle(s) – Single Phase
Model: 5PX1500IRT2UG2
Warranty: 2 Year on Battery
The new Eaton 5PX Gen2 UPS provides Enterprise Networks and Edge IT equipment with best-in-class line-interactive power protection maximizing IT space and Service Continuity.
Eaton 5PX Gen 2 offers powerful tools to remotely monitor, integrate with IT architecture and remotely deploy / maintain large installed base of UPSs.
- Works adequately in situations where the supply is prone to sags and surges
- Keep your sensitive devices powered with a backup of up to 5 minute at full load
- 1.50 kW load capacity – backup power for your valuable electronics
- 1.50 kVA load capacity – work without any interruption during power outages
Eaton 5PX1500IRT2UG2 Specifications
General Specifications
| Product Name | 5PX1500IRT2UG2 1500VA Rack/Tower UPS |
|---|---|
| Catalog Number | 5PX1500IRT2UG2 |
| Manufacturer Part Number | 921063060 |
| UPC | 743172104861 |
| Product Series | 5PX |
| Product Type | Line-interactive UPS |
| Product Height | 85.5 mm |
| Product Width | 438 mm |
| Rack Height | 2U |
| Weight | 22.40 kg |
| Product Color | Black Silver |
| Certifications | CE cTUVus EAC Cm UKCA Ukr KCC IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA 22.2 |
Battery
| Battery Chemistry | Lead Acid |
|---|---|
| Battery Size | 12V |
| Battery Capacity | 9000 mAh |
| Number of Batteries | 4 |
| Battery Characteristics | Maintenance-free |
| Replaceable Battery | Yes |
| Backup/Run Time (Half Load) | 14 Minute |
| Backup/Run Time (Full Load) | 5 Minute |
Electrical Output
| Receptacle Detail | 8 x IEC 60320 C13 (10A) |
|---|---|
| Receptacle Type | IEC 60320 C13 |
| Load Capacity (Watt) | 1.50 kW |
| Load Capacity (VA) | 1.50 kVA |
| Waveform Type | Sine Wave |
| Output Voltage | 200 V AC 208 V AC 220 V AC 230 V AC 240 V AC |
| Output Power Factor | 1 |
| Phase | Single Phase |
Electrical Input
| Plug/Connector Type | IEC 60320 C14 (10A) |
|---|---|
| Input Voltage | 230 V AC |
| Input Voltage Range | 150 V AC – 294 V AC |
| Input Frequency | 40 Hz – 70 Hz |
Communications & Management
| Status Indicators | Multilingual Graphical LCD Display |
|---|---|
| Display | LCD |
| Network Management | Dry Contact DB-9 RS-232 |
| USB | Yes |
| Serial Port | Yes |
| USB (HID Compliant) Port | Yes |
Application/Usage
| Application/Usage | IT Equipment VoIP Storage System Server Network Equipment |
|---|
Environmental & Compliance
| Environmentally Friendly | Yes |
|---|---|
| Energy Star | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Restriction of Hazardous Substances (RoHS) |
Package Contents
| Package Contents | 5PX1500IRT2UG2 1500VA Rack/Tower UPS Rack-mounting Kit 2 x Supports for Tower Mounting Cable Locking System USB Cable Serial Cable 2 x IEC-IEC Cables Quickstart Guide Safety Instructions |
|---|
Shipping Information
| Shipping Weight | 27.9 KG |
|---|---|
| Shipping Dimensions (H x W x L) | 24 x 50 x 58 |
