APC Back-UPS, 625VA, Floor, 230V, 3 Universal outlets, AVR
Model: BX625CI-MS
Warranty: 24 months
Download Datasheet
APC BX625CI-MS Specifications
Main
| Main input voltage |
230 V AC 1 phase |
| Maximum input current |
3 A |
| Input protection |
3-pole circuit breaker |
| Switching current capacity |
7 A |
| Efficiency at full load |
151…299 V |
| Input frequency |
45…65 Hz |
| Output voltage |
230 V AC 1 phase |
| Rated power in W |
325 W |
| Rated power in VA |
625 VA |
| Output connection |
3 universal |
| Type of USB power supply |
None |
| Maximum configurable power in VA |
625 VA |
| Maximum configurable power in W |
325 W |
| Transfer time |
4 ms typical : 8 ms maximum |
| UPS topology |
Line interactive |
| Waveform type |
Square wave |
| Efficiency |
65.3 % (full load), 75.8 % (half load) |
| Output frequency |
50/60 Hz +/- 1 Hz unsynchronised |
Complementary
| Battery type |
Lead-acid internal included |
| Control panel |
LED Status display with on line : on battery |
| UPS connectivity |
None |
| Surge energy rating |
273 J |
| Cable length |
1.2 m |
| Number of cables |
1 |
| Color |
Black |
| Height |
278.5 mm |
| Width |
160 mm |
| Depth |
88.5 mm |
| Product weight |
5 kg |
| Mounting preference |
No preference |
| Mounting mode |
Not rack-mountable |
| Two post mountable |
0 |
| USB compatible |
Yes |
| Mounting mode |
Tower |
| Number of power module filled slots |
0 |
| Number of power module free slots |
0 |
| Additional specification |
Entry level |
| Redundant |
No |
| Range of product |
Back-UPS |
| Product or component type |
Uninterruptible power supply (UPS) |
Environment
| Standard |
EN/IEC 62040-1:2019/A11:2021; EN/IEC 62040-2:2006/AC:2006; EN/IEC 62040-2:2018 |
| Ambient air temperature for operation |
0…40 °C |
| Ambient air temperature for storage |
-15…40 °C |
| Relative humidity |
0…95 % |
| Storage relative humidity |
0…95 % |
| Acoustic level |
45 dBA |
Batteries & Runtime
| Battery type |
Lead-acid battery |
| Extendable runtime |
0 |
| Included battery module |
1 |
| Empty battery slot |
0 |
| Typical recharge time |
6 h |
| RBC quantity |
1 |
| Battery life |
2…4 year(s) |
| Battery charging power |
11 W rated |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
39.9 cm |
| Package 1 Width |
12.8 cm |
| Package 1 Length |
21.5 cm |
| Package 1 Weight |
5.2 kg |
| SCC14 |
10731304308178 |
